P/N 00142031 belongs to the SIPLACE Type III linear vibratory feeder family for components supplied in stick or tube magazines. Its feeding task is fundamentally different from an X Smart tape feeder: components are advanced from the magazine toward the pickup position by the vibratory feeder system.
If stick-fed components hesitate, fail to advance consistently or reach the pickup point irregularly, the Type III feeder, magazine setup and component fit are among the areas to inspect. Correct magazine selection is therefore part of the feeder setup, not an afterthought.
00142031 Stick Feeder Specifications
| Base Part Number | 00142031 |
|---|---|
| Known Revision | 00142031-04 |
| Feeder Type | Linear vibratory feeder Type III |
| Assembly Level | Complete feeder module |
| Component Supply | Stick / tube magazine |
| Magazine Widths | 4.5 mm, 9.5 mm, 15 mm and 30 mm for the 00142031-04 configuration |
| Drive Type | Electrically driven vibratory feeding |
The main purchasing check is the stick-magazine configuration, not tape width. Confirm the complete suffix and magazine format before treating another vibratory feeder as interchangeable.
For matching, provide the full feeder label, machine model, stick or tube dimensions, component dimensions and feeder photos. Other component-supply options can be reviewed in the ASM SIPLACE feeder category.
