ASM SIPLACE 03083001 is the component sensor documented for the CP20A placement head. The most important selection point is head generation: ASM lists separate component-sensor part numbers for CP20A, CPP and CP20P.
03083001S03 belongs to the CP20A application. 03037106 is separately documented as the CPP component sensor, while 03092400 is listed for CP20P. A purchase request that only says component sensor is therefore not specific enough.
03083001 Sensor Specifications
| Part Number | 03083001 |
| Documented Revision | 03083001S03 |
| Part Type | Component sensor |
| Head Application | CP20A |
| CPP Reference | 03037106 — CPP component sensor |
| CP20P Reference | 03092400 — CP20P sensor |
| Key Matching Point | Confirm head generation and complete installed sensor label |
When a component-detection problem appears on a CP20A head, the sensor should be evaluated together with its immediate installation and connection path. Contamination, mounting condition, protective parts or a connection issue can affect the same detection path without proving that the sensor itself is defective.
The generation check should come before the replacement decision. A sensor selected from appearance or from the generic CP20 family name can move the repair to the wrong head version even when the parts look closely related.
For other CP20A, CPP and CP20P service items, see our ASM SIPLACE SMT head parts. Send the full sensor label, head identification, photos and alarm information when requesting 03083001.
