ASM SIPLACE 00373245 is a distributor PCB for the 3×8mm S feeder SL/S assembly. Its main selection risk is simple but important: it is not the same board as the 00345355 control PCB used in the same 3×8mm S feeder family.
A purchase request that only says 3×8mm feeder board is therefore incomplete. Before ordering, confirm whether the failed board is the distributor PCB, the control PCB or another internal feeder assembly.
00373245 Feeder PCB Specifications
| Part Number | 00373245 |
| Documented Revision | 00373245-01 |
| Part Type | Distributor PCB |
| Application | 3×8mm S feeder SL/S |
| Assembly Level | Internal feeder PCB |
| Confusing Part | 00345355 — 3×8mm S feeder control PCB |
| Repair Decision | Confirm which internal board has failed before replacing the PCB |
Feeder symptoms should still be traced through the actual mechanism. Tape path resistance, drive engagement and other mechanical causes can create unstable feeding without either PCB being defective. Once the mechanical path is normal, the electrical diagnosis can be narrowed between the distributor PCB, the separate control PCB and their connections.
The value of board-level identification is that a serviceable 3×8mm feeder does not need to be replaced as a complete unit simply because one internal PCB has failed. The benefit only exists when the failed board has been identified correctly.
Send the feeder label and a clear photo of the installed PCB when requesting 00373245. Standard stocked boards can normally be dispatched within 24–48 hours after matching. Other feeder repair items can be found under ASM SIPLACE feeder parts.
